FRP Composite Poles
FRP Composite Poles for Highways and Expressways
India's expanding national highway and expressway network requires lighting infrastructure that performs reliably across vast geographical stretches — from the Thar desert to the Himalayan foothills to coastal causeways. Helipole FRP composite poles are engineered for this scale: lightweight enough to install in remote locations without heavy cranes, structurally rated for 180 kmph wind loads, and built to last 40-50 years without painting, galvanising, or replacement.
Highway Project Realities — and the FRP Advantage
Highway lighting deployment differs fundamentally from urban projects. Poles are installed every 30-40 metres across hundreds of kilometres, often in locations with limited road access and minimal civil infrastructure. Maintenance after installation is logistically expensive. The pole itself becomes a long-term commitment.
- Lightweight installation: 1/3rd the weight of steel, 1/8th the weight of concrete. Manual installation possible up to 9m height. Reduced crane and lifting equipment cost.
- Lower transport cost: More poles per truck. Critical for projects spanning multiple states.000
- Zero corrosion: No painting maintenance schedule. No galvanising touch-ups. No surface degradation in monsoon humidity, dust, or industrial corridor pollution.
- Long service life: 40-50 years means the pole outlasts at least two LED luminaire upgrade cycles — reducing total infrastructure cost across the highway's design life.
- Wind load performance: 180 kmph rating handles cyclone-prone east coast highways and high-altitude wind exposures.
- Vehicle impact behaviour: FRP fractures cleanly rather than buckling like steel — reducing post-impact hazard to traffic.
Highway Applications
- National highway main carriageway lighting
- Expressway and access-controlled corridor lighting
- Service road and slip road lighting
- Toll plaza area lighting
- Highway interchange and flyover deck lighting
- Rural road and PMGSY project lighting
- Median and central reservation lighting
- Highway rest area and dhaba lighting
Specifications
- Heights: 6m, 8m, 9m, 10m, 12m standard; custom up to 15m
- Single arm, double arm, and high-mast configurations
- Burial type or flange-mounted on PCC/RCC foundation
- 180 kmph wind load rating per IS 875 and BS EN 40
- 40-50 year service life with zero painting/coating maintenance
- UV-stabilised gel-coat — full RAL colour palette
- Internal cable routing for clean appearance and theft resistance
Applications
- Coastal road and beachfront lighting
- Port and harbour lighting (cargo yards, container terminals, jetties)
- Cyclone-prone highways along the eastern coast
- Naval and coast guard installations
- Coastal industrial estates and SEZs
- Shipyards and offshore support facilities
- Tourism infrastructure on coastal stretches
Enquiry Form
For highway pole specifications, NHAI-compliant designs, EPC tender support, or bulk supply quotation, please contact our team.
